The Worldwide first WLTC compliant Driving Robot for EMC environments!

The SAP2000V comprises:

• Human drive style

• Speed control

• Integrated Battery

• Various styles selectable

• Dynamic and accurate

• Actuator and drive system

• Extreme high repeatability

• All module weight <16 kgs for

• Comfortable setup

• Very fast & simple vehicle

• Installation under 10 mins

Standard robot system for computer controlled driving of passenger cars and light commercial vehicles on EMC test stands. Humanlike drive style and highest grade of repeatability allow the use for emission tests, mileage accumulation, climate tests, etc. Different levels of systems, actuator configurations and integration interfaces are available.

STÄHLE AUTOPILOTS are employed throughout the world for testing of vehicles, vehicle components, fuels and lubricants, etc. on roll test beds.

Optimization of consumption and exhaust gas parameters demands extremely high reproducibility of driving style. AUTOPILOTS will achieve deviations in the distance driven which are < 1m with a 17.86 km long emission cycle, as well as standard deviations of only 0.05% for consumption measurements.

Quick and easy installation of the driving mechanism in the vehicle, plus a learning cycle where, independent of any test and at one go, it will learn all the control parameters fully automatically, guarantee short setup and pre-run times, along with simple operation.
